Zhejiang Xinna Medical Device Technology Co., Ltd.

1.2 micron IV Filter for infusion therapy

รายละเอียดสินค้า:
สถานที่กำเนิด: จีน
ชื่อแบรนด์: OEM avaliable
ได้รับการรับรอง: YY 0286.1 GB 8368-2018 ISO9001
หมายเลขรุ่น: F33
การชำระเงิน:
จำนวนสั่งซื้อขั้นต่ำ: 100,000 ชิ้น
ราคา: $0.15-$0.22 per piece
รายละเอียดการบรรจุ: 750 ชิ้นต่อแพ็คพร้อมฉลาก 4 แพ็คต่อกล่องหรือปรับแต่งได้
เวลาการส่งมอบ: 30 วัน
เงื่อนไขการชำระเงิน: L/C, T/T
  • ข้อมูลรายละเอียด
  • รายละเอียดสินค้า

ข้อมูลรายละเอียด

ชื่อสินค้า: ตัวกรอง 1.2 ไมครอน IV ที่ใช้แล้ว ที่อยู่อาศัยตัวกรอง: เอบีเอส
ขนาดรูพรุน: 1.2 ไมโครเมตร วัสดุปานกลาง: PES, PTFE สำหรับช่องระบายอากาศ
หยุดความสูงของของเหลว: ≥1.5เมตร โหมดการประกอบ: การหลอมด้วยความร้อนหรือการเชื่อมด้วยคลื่นเสียงเหนือเสียง
การทำหมัน: ไม่ผ่านการฆ่าเชื้อ/EOS ประเภท: เอฟ, แบบใช้แล้วทิ้ง
ข้อดี: ระบบหยุดของเหลวอัตโนมัติ สี: เป็นธรรมชาติและกันแสงได้
ความเหมาะสม: เข้ากันได้กับท่อ IV มาตรฐาน การรับประกัน: 3 ปี
แอปพลิเคชัน: ชุดแช่ ประเทศกําเนิด: จีน
เน้น:

1.2 micron

,

iv filter 1.2μm

,

infusion set

รายละเอียดสินค้า

IV Filter With Hydrophilic PES-pp 1.2μm and Hydrophobic PTFE 0.45μm for infusion set



F33 IV Filter is an air eliminating filter for the removal of inadvertent particulate debris and other components like incomplete mixing of drugs and entrained air in catheter which may be found in solutions intended for intravenous use. The filtration efficiency of the membrane and the overall design of the filter can impact the safety of drug delivery for human beings.



Features :

  • Easy to connect to IV tubing sets with standard luer inlet and outlet slip
  • Precision filtration of fine particles
  • High retention efficiency
  • Range of pore size options
  • Automatic air-stop
  • Lightproof-colored housings for light sensitive drugs is available
  • Printing available for ease of product identification

Specifications:





Dimensions: 57*29.5*0.94mm(inlet/outlet connector included)
Weight: 5.7-5.8g
Filtration area: 6.0CM2
Venting area: 0.54CM2
Venting air flow rate: 25ml/min@5kpa
Max burst pressure: 3.6bar(52.5psi)
Operating Temp: 5-40℃
Storage Temp: 0-50℃
Filtration rate: PES-PP 5.0μm ≥95%,
PES-PP 3.0/2.0/1.2μm ≥90%
Min water flow rate: PES-PP 1.2μm ≥500ml/10min@10kpa
PES-PP 2μm ≥600ml/10min@10kpa
PES-PP 3μm ≥800ml/10min@10kpa
PES-PP 5μm ≥1000ml/10min@10kpa
Sterilization: Ethlene Oxide(Max 60℃)



Applications:

  • Filter is designed for use in filtration of intravenous for removal of particles larger than 1.2μm
  • Infusion set



Package&Label:



3000pcs/box, 4 inner PE bags with 750 pcs inside each. each bag is sealed separately and cushion between each other.
Each bag is labeled with information as following, different lots in one box are closed separately and labeled seperately to prevent.
